House with attic in traditional style with usable area 274,81 m2. House with a large garage. Minimum size of a plot needed for building a house is 37x27,4 m.
Author:
mgr inż. arch. LESZEK KALANDYK
| 1. Usable area | 274,81 m² |
| 2. Additional area | 72,32 m² |
| 3. Total surface | 543 m² |
| 4. Building area | 305 m² |
| 5. Net volume | 912,85 m³ |
| 6. Gross volume | 1210,37 m³ |
| 7. Building height | 9,2 m |
| 8. Roof angle | 43 ° |
| 9. Roof area | 658,7 m² |
| 10. Minimum plot size | 37 x 27,4 m |
| 1. Foundation footings | made of reinforced concrete |
| 2. Foundation walls | concrete |
| 3. Exterior walls | Porotherm 30 Profi ceramic hollow bricks by Wienerberger + Termonium styrofoam facade by Termo Organika company with a thickness of 20 cm |
| 4. Interior walls | Porotherm 25 and 11.5 Profi ceramic hollow bricks by Wienerberger |
| 5. Ceiling | reinforced concrete, monolithic |
| 6. Roof construction | wooden + covered with Thermano thermal insulation board with a thickness of 18 cm |
| 7. Roofing | KoraTech WITH CERAMIC TILE Flat Orea 9, grey engobe roof tile by Wienerberger |
| 8. Facade | silicone plaster, color white, IBISA FALLS clinker brick by KMK Klinkier firm |
| 9. Windows and doors | WOODWORK by SOKӣKA Windows and Doors, color: honey |
| 10. Type of heating | gas, underfloor |
| 11. Ventilation | mechanical with recuperation |
Ground floor
| Usable area | 151,38 m2 |
| 1. Lobby | 8,78 m2 |
| 2. Kitchen | 17,95 m2 |
| 3. Canteen | 28,82 m2 |
| 4. Living room | 33 m2 |
| 5. Corridor | 27,77 m2 |
| 6. Boiler room | 6,76 m2 |
| 7. Pantry | 5,57 m2 |
| 8. Corridor 2 | 2,61 m2 |
| 9. Restroom | 3,4 m2 |
| 10. Wardrobe | 3,4 m2 |
| 11. Office | 13,32 m2 |
| 12. Carport | 72,32 m2 |
Attic
| Usable area | 123,43 (160,08) m2 |
| 1. Corridor | (25,50) 23,96 m2 |
| 2. Wardrobe | (12,96) 10,12 m2 |
| 3. Bedroom | (21,37) 11,70 m2 |
| 4. Bathroom | (11,77) 9,68 m2 |
| 5. Bathroom 2 | (13,73) 11,15 m2 |
| 6. Laundry room | (5,41) 3,10 m2 |
| 7. Room | (24,64) 19,35 m2 |
| 8. Room 2 | (24,64) 19,35 m2 |
| 9. Room 3 | (20,06) 15,02 m2 |
What does the project contain?
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
